Customized Plastic CNC Turning Service
Product Details
Product Name: Customized Plastic CNC Turning Service
Machining Type: CNC Turning and Milling
Machining Accuracy: High
Lathe Milling Type: CNC lathe +CNC machining
Material: Plastic
Tolerance: ±0.05mm, can be customized according to customer requirements, the most precise tolerance up to ±0.003mm
Proofing Period: 3-7 days
Production Cycle: According to the production quantity and product structure to determine
Surface Treatment: As machined
Origin: Dongguan, China
High Precision OEM CNC Machining Parts Supplier
| Service |
CNC Turning, CNC Milling, Laser Cutting, Wire Cutting, Stamping, Electric Discharge Machining (EDM), etc. |
| Materials |
1). Aluminum: AL 6061-T6, 6063, 7075-T, etc
2). Stainless steel: 303, 304, 316L, 17-4(SUS630), etc
3). Steel: 45#, Q235, Q345B, etc
4). Titanium: TA1, TA2/GR2, TA4/GR5, etc
5). Brass: C36000 (HPb62), etc
6). Copper, bronze, POM, Acrylic, PC, etc |
| Surface Treatment |
Sandblasting, Anodize, Zinc/Nickl Plating, Polish |
| Processing Technology |
CNC machining parts, turning/milling process |
| MOQ |
1pcs |
| Lead Time |
Sample: 3-10 days
Mass Production: within 10-25 days after receiving the deposit |
| Package |
1) pp bags + carton or wooden case
2) according to customers' requirements
3) negotiable |
| Payment Terms |
T/T, Paypal |
Raw Material for CNC Turning
We are also an expert of CNC turning screw manufacturing. For example, customized slotted head set screw with flat end is widely used in electronic revenue meter which can perform fine or coarse adjustment. The screw materials we are able to manufacture range from brass C3604, copper C11000, stainless steel 303 304 316L, to aluminum alloy 2011 6061 T6.
Finally, at Zhaoyi, we use powerful CNC lathe machines for manufacturing CNC machined parts. You are welcome to visit our official website for more understanding about our CNC production capability and send us inquiry for free project review.
Matters Need Attention when CNC Turning
The technic for CNC lathe is similar with general lathe. But for CNC lathe machining it' s one time clamping, finish all machining process continuously and automatically. There are several matters need to pay attention when machining.
1. Reasonable choice for cutting parameters: The material of workpiece, cutting toolings and cutting conditions are three important elements for high efficiency metal turning process. These elements decide the machining time, the toolings' life and component's quality. Economic and efficiency machining process must have chosen reasonable cutting conditions. Three important elements for cutting condition are: cutting rate, advancing speed and the depth of cutting. Along with the increase of cutting rate, the temperature of tooling will become higher, it will lead to mechanical, chemical and high temperature abrasion.Improving 20% of cutting rate, the tooling' s life will reduce 1/2. The advancing speed and depth of cutting will also effect the tooling' s life. So we should consider these elements when choosing the cutting rate: the workpiece' s material, hardness, cutting conditions, advancing speed, depth of cutting, etc.
2. When rough machining, you should choose tooling with high strength and good durability to meet the requirement of high turning depth and high advancing speed.To meet the requirement of precision, we should choose high precision toolings when rough machining. Choosing folder plate knife to reduce the time for changing knife.
3. Reasonable choice of clamp: choosing universal clamp than special clamp.
4. Establish the process course: Ensure to reach the requirements of precision and surface roughness. The process course should be as short as possible to reduce the idle stroke of toolings.
5. If there is too many allowance of workpiece, especially like some foundry and casting parts, we always use general lathe to machining these allowance.
Application of CNC Machining Parts
FAQ
Q: If I need the parts urgent, can you help?
A: Yes, we are here to help. Production time is flexible. If you need the parts urgent, please tell us the delivery time you need. We will do our best to adjust the production schedule priority.
Q: What surface treatment services do you have?
A: Customer's Demand, Anodized, Plating, PVD, Nickel Plating, Sandblasting, Powder Cating, Polishing, Multi-color anodized, Painting, etc.
Q: Is the sample available? free?
A: Samples are available and some are free.
Q: Why there is tolling cost?
A: It's mold cost, indispensabel production process. Only need to pay for first order, and we'll bear maintenance of mold damage.
Q: Can you advise on suitable materials for us?
A: Yes, we are very knowledgeable and can recommend the best grade materials for your application.
